Lodgepole Barndominium
C$2,200.00
The Lodgepole Barndominium is the definitive plan for your acreage, merging modern farmhouse style with timeless, rugged design. The great room is a show-stopper, featuring vaulted timber-trussed ceilings and a stone fireplace that creates an impressive hub for entertaining.
The gourmet kitchen with a large island and walk-in pantry seamlessly serves both family life and social gatherings. Upstairs, a versatile loft offers the ideal space for a home office or media lounge.
Designed for acreage living, large windows frame your property's views and covered patios extend your life outdoors. The essential oversized garage provides a true workshop for all your projects, equipment, and toys. The Lodgepole is a sophisticated sanctuary built for a lifetime of memories.
Quantity
Plan Specifications
Main Floor: 1792 sqft
Garage: 1232 sqft
Loft: 1128 sqft
Bedrooms: 4
Bathrooms: 2.5
Features
-
Oversized Attached Garage / Workshop
-
Slab-on-Grade design
-
Open-concept great room combining living, dining, and kitchen.
-
Vaulted ceilings in the main living area featuring decorative heavy timber trusses.
-
Gourmet kitchen with a large central island perfect for food prep and casual dining.
-
Spacious walk-in pantry with ample storage.
-
Main Floor Primary Suite
-
Versatile loft space overlooking the great room below.
-
Generously sized bedrooms for family or guests.
-
Full bathroom to service the upper level.
What's Included?
A2.0 - Floor Plans
-
Fully dimensioned layouts for all floors.
-
Locations and sizes of all interior/exterior walls, doors, and windows.
-
Identification of structural members (beams, columns, headers).
-
Appliance location and identification
-
Ceiling heights and transitions noted.
-
Suggested furniture layouts
A3.0 - Exterior Elevations
-
Front, rear, and both side elevations drawn to scale.
-
Callouts and specifications for all exterior materials and finishes.
-
Annotation of roof pitches, overhangs, and vertical dimensions.
-
Exterior grade lines indicated.
A4.0 - Building Sections & Details
-
Transverse and longitudinal cross-sections showing building assembly.
-
Detailed wall assemblies from footing to roof structure.
-
Specifications for insulation, air/vapor barriers, and building envelope components.
-
Enlarged construction details for critical connections and assemblies.
E1.0 - Schematic Electrical Plan
-
Suggested location of all receptacles, switches, and lighting fixtures.
-
Indicated placement for all smoke and carbon monoxide detectors as per code.
S1.0 - Foundation Layout for Engineer Approval
-
Dimensioned foundation and footing plan.
-
Slab thickness and required notes.
What's not included?
- Engineering Stamp
- Site Plan (can be completed upon request)
- Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
- Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
- Energy calculations
Notes & Disclaimers
-
Professional Seals: Drawings are provided without an architectural or engineering seal. A local licensed professional is recommended to review and seal the documents for submission to the Authority Having Jurisdiction (AHJ).
-
Scope of Drawings: The scope is limited to architectural drawings. HVAC (mechanical), plumbing, and site plans are excluded and must be designed by qualified local trades or professionals.
-
Compliance: The purchaser is solely responsible for ensuring compliance with all local bylaws, community covenants, and specific site conditions.
-
Please review our Terms and Conditions page prior to your purchase
Looking to Modify?
If this plan requires a few tweaks to make it perfect for you, we are happy to help! Please contact us regarding any customizations to this plan prior to purchasing.
All changes are additional, and priced at an hourly rate.
